HC5861-老毛子Padavan(2.4Gwifi稳定) #7
Description
固件版本
3.4.3.9-099_22-02-1
可用空间
手动安装了 iperf3 htop,剩余空间
[RT-AC1200HP /home/root]# df -h
Filesystem Size Used Available Use% Mounted on
rootfs 12.0M 12.0M 0 100% /
/dev/root 12.0M 12.0M 0 100% /
tmpfs 8.0K 0 8.0K 0% /dev
tmpfs 7.5M 2.1M 5.5M 27% /etc
tmpfs 1.0M 12.0K 1012.0K 1% /home
tmpfs 8.0K 0 8.0K 0% /media
tmpfs 8.0K 0 8.0K 0% /mnt
tmpfs 61.0M 8.8M 52.2M 14% /tmp
tmpfs 4.0M 76.0K 3.9M 2% /var
tmpfs 61.0M 8.8M 52.2M 14% /opt
tmpfs 61.0M 8.8M 52.2M 14% /www/Advanced_Extensions_app07.asp
tmpfs 61.0M 8.8M 52.2M 14% /www/Advanced_Extensions_app08.asp
tmpfs 61.0M 8.8M 52.2M 14% /www/Advanced_Extensions_app22.asp
tmpfs 61.0M 8.8M 52.2M 14% /www/Advanced_Extensions_app21.asp
tmpfs 61.0M 8.8M 52.2M 14% /www/Advanced_Extensions_app24.asp
tmpfs 61.0M 8.8M 52.2M 14% /www/Advanced_Extensions_app16.asp
tmpfs 61.0M 8.8M 52.2M 14% /www/Advanced_Extensions_app14.asp
tmpfs 61.0M 8.8M 52.2M 14% /www/Advanced_Extensions_app09.asp
tmpfs 61.0M 8.8M 52.2M 14% /www/Advanced_Extensions_app10.asp
tmpfs 61.0M 8.8M 52.2M 14% /www/Advanced_Extensions_app11.asp
tmpfs 61.0M 8.8M 52.2M 14% /www/Advanced_Extensions_app20.asp
tmpfs 61.0M 8.8M 52.2M 14% /www/Advanced_Extensions_app12.asp
tmpfs 61.0M 8.8M 52.2M 14% /www/Advanced_Extensions_app15.asp
tmpfs 61.0M 8.8M 52.2M 14% /www/Advanced_Extensions_app13.asp
tmpfs 61.0M 8.8M 52.2M 14% /www/Advanced_Extensions_app23.asp
tmpfs 61.0M 8.8M 52.2M 14% /www/Advanced_Extensions_app17.asp
tmpfs 61.0M 8.8M 52.2M 14% /www/Advanced_Extensions_app01.asp
tmpfs 61.0M 8.8M 52.2M 14% /www/Advanced_Extensions_app19.asp
tmpfs 61.0M 8.8M 52.2M 14% /www/Advanced_Extensions_app02.asp
tmpfs 61.0M 8.8M 52.2M 14% /www/Advanced_Extensions_app04.asp
tmpfs 61.0M 8.8M 52.2M 14% /www/Advanced_Extensions_app03.asp
tmpfs 61.0M 8.8M 52.2M 14% /www/Advanced_Extensions_app06.asp
tmpfs 61.0M 8.8M 52.2M 14% /www/Advanced_Extensions_app05.asp
tmpfs 61.0M 8.8M 52.2M 14% /www/Advanced_Extensions_app18.asp
[2.4G]距离路由器3米，加0堵墙
$ ./iperf3.exe -c 192.168.7.1
Connecting to host 192.168.7.1, port 5201
[ 4] local 192.168.7.18 port 4426 connected to 192.168.7.1 port 5201
[ ID] Interval Transfer Bandwidth
[ 4] 0.00-1.01 sec 1.75 MBytes 14.6 Mbits/sec
[ 4] 1.01-2.00 sec 2.12 MBytes 17.9 Mbits/sec
[ 4] 2.00-3.01 sec 2.62 MBytes 21.9 Mbits/sec
[ 4] 3.01-4.00 sec 896 KBytes 7.38 Mbits/sec
[ 4] 4.00-5.00 sec 768 KBytes 6.30 Mbits/sec
[ 4] 5.00-6.00 sec 2.38 MBytes 19.9 Mbits/sec
[ 4] 6.00-7.00 sec 1.88 MBytes 15.8 Mbits/sec
[ 4] 7.00-8.01 sec 1.62 MBytes 13.5 Mbits/sec
[ 4] 8.01-9.01 sec 2.50 MBytes 20.9 Mbits/sec
[ 4] 9.01-10.00 sec 1.00 MBytes 8.49 Mbits/sec
- - - - - - - - - - - - - - - - - - - - - - - - -
[ ID] Interval Transfer Bandwidth
[ 4] 0.00-10.00 sec 17.5 MBytes 14.7 Mbits/sec sender
[ 4] 0.00-10.00 sec 17.5 MBytes 14.7 Mbits/sec receiver
[2.4G]距离路由器3米，加1堵墙
$ ./iperf3.exe -c 192.168.7.1
Connecting to host 192.168.7.1, port 5201
[ 4] local 192.168.7.18 port 4673 connected to 192.168.7.1 port 5201
[ ID] Interval Transfer Bandwidth
[ 4] 0.00-1.00 sec 1.25 MBytes 10.4 Mbits/sec
[ 4] 1.00-2.00 sec 896 KBytes 7.37 Mbits/sec
[ 4] 2.00-3.00 sec 640 KBytes 5.23 Mbits/sec
[ 4] 3.00-4.01 sec 512 KBytes 4.17 Mbits/sec
[ 4] 4.01-5.01 sec 384 KBytes 3.16 Mbits/sec
[ 4] 5.01-6.01 sec 640 KBytes 5.22 Mbits/sec
[ 4] 6.01-7.00 sec 512 KBytes 4.23 Mbits/sec
[ 4] 7.00-8.01 sec 512 KBytes 4.16 Mbits/sec
[ 4] 8.01-9.01 sec 1.00 MBytes 8.35 Mbits/sec
[ 4] 9.01-10.01 sec 1.25 MBytes 10.5 Mbits/sec
- - - - - - - - - - - - - - - - - - - - - - - - -
[ ID] Interval Transfer Bandwidth
[ 4] 0.00-10.01 sec 7.50 MBytes 6.28 Mbits/sec sender
[ 4] 0.00-10.01 sec 7.42 MBytes 6.22 Mbits/sec receiver
[2.4G]距离路由器4米，加2堵墙
$ ./iperf3.exe -c 192.168.7.1
Connecting to host 192.168.7.1, port 5201
[ 4] local 192.168.7.18 port 4857 connected to 192.168.7.1 port 5201
[ ID] Interval Transfer Bandwidth
[ 4] 0.00-1.02 sec 384 KBytes 3.10 Mbits/sec
[ 4] 1.02-2.01 sec 128 KBytes 1.06 Mbits/sec
[ 4] 2.01-3.01 sec 384 KBytes 3.13 Mbits/sec
[ 4] 3.01-4.01 sec 256 KBytes 2.10 Mbits/sec
[ 4] 4.01-5.00 sec 384 KBytes 3.16 Mbits/sec
[ 4] 5.00-6.01 sec 384 KBytes 3.13 Mbits/sec
[ 4] 6.01-7.01 sec 128 KBytes 1.04 Mbits/sec
[ 4] 7.01-8.01 sec 384 KBytes 3.14 Mbits/sec
[ 4] 8.01-9.01 sec 384 KBytes 3.16 Mbits/sec
[ 4] 9.01-10.01 sec 256 KBytes 2.09 Mbits/sec
- - - - - - - - - - - - - - - - - - - - - - - - -
[ ID] Interval Transfer Bandwidth
[ 4] 0.00-10.01 sec 3.00 MBytes 2.51 Mbits/sec sender
[ 4] 0.00-10.01 sec 2.92 MBytes 2.45 Mbits/sec receiver
[5G]距离路由器3米，加0堵墙
$ ./iperf3.exe -c 192.168.7.1
Connecting to host 192.168.7.1, port 5201
[ 4] local 192.168.7.18 port 12437 connected to 192.168.7.1 port 5201
[ ID] Interval Transfer Bandwidth
[ 4] 0.00-1.01 sec 15.2 MBytes 127 Mbits/sec
[ 4] 1.01-2.00 sec 10.9 MBytes 91.8 Mbits/sec
[ 4] 2.00-3.01 sec 14.1 MBytes 118 Mbits/sec
[ 4] 3.01-4.00 sec 20.6 MBytes 174 Mbits/sec
[ 4] 4.00-5.00 sec 14.8 MBytes 124 Mbits/sec
[ 4] 5.00-6.01 sec 15.4 MBytes 128 Mbits/sec
[ 4] 6.01-7.00 sec 13.2 MBytes 112 Mbits/sec
[ 4] 7.00-8.00 sec 15.2 MBytes 128 Mbits/sec
[ 4] 8.00-9.01 sec 17.2 MBytes 143 Mbits/sec
[ 4] 9.01-10.01 sec 11.5 MBytes 96.8 Mbits/sec
- - - - - - - - - - - - - - - - - - - - - - - - -
[ ID] Interval Transfer Bandwidth
[ 4] 0.00-10.01 sec 148 MBytes 124 Mbits/sec sender
[ 4] 0.00-10.01 sec 148 MBytes 124 Mbits/sec receiver
- - - - - - - - - - - - - - - - - - - - - - - - -
[ ID] Interval Transfer Bitrate
[ 5] 0.00-10.02 sec 160 MBytes 134 Mbits/sec receiver
[5G]距离路由器3米，加1堵墙
[5G]距离路由器4米，加2堵墙
无信号
