The Abelian Sandpile Kata

In this kata, you will be challenged to implement the abelian sandpile, a type of cellular automata. See this Wikipedia article for a more technical description.

Description

A sandpile is a 2-dimensional square array with the following properties:

Each cell of the array contains an integer between zero and three.

You can think of this as being the number of grains of sand in that location on the pile.

Example: A 4 x 4 sandpile.

Sand can be added at any location.

We can add a grain of sand to any cell in the pile.

Example: Adding one to the location (2, 1).

Sand cannot be removed directly.

There is no method to remove sand from a particular location on the pile. It is possible to remove sand indirectly via the method described below.

If adding sand to a location brings its value above four causes that location to "topple."

This causes its value to be reduced by four and then each adjacent neighbor to increase by one. (Note, cells must be touching to be considered adjacent. Two cells which share a corner but not an edge are not adjacent.)

	➡️

Example: Adding one to the location (1, 1) increased it's value to 4. This caused a topple, which resulted in (1, 1) being set to 0 and the four adjacent cells going up by one.

If a cell on the boundary topples, grains fall off the pile and are removed.

Sand is removed from the table when a cell on the boundary topples. This could either be an edge cell, or a corner cell.

	➡️

Example: Adding a grain to cell (0, 1) caused it to topple. Because it was on the boundary, its three neighbors each increased by one, and the last grain "fell off the pile"

Toppling could cause other cells to topple.

If a cell topples and one of its neighbors grows above four grains, then the toppling rule applies to that neighbor. This will continue in an avalanche until all cells in the pile have less than four grains.

	➡️		➡️

Example: Adding a grain to (0, 2) caused that location to topple. This in turn caused the location (0, 3) to topple. After this, each cell has less than four grains, so topplig ceases.

Kata Challenges

Try to get through as many levels as you can!

Level 1

Create an implementation of the abelian sandpile. The user should be able to create sandpiles of any size, add grains of sand to a location on the pile, and inspect the contents of the pile.

Level 2

Give the user the ability to add sandpiles together, provided they are the same size.

Level 3

Create a way to visualize a sandpile.

Level 4

Use your visualization to create an animation. Starting with a blank sandpile, continue to drop one grain at a time at a target location, and display what patterns emerge from this process.

BONUS

Attempt challenge levels 1-4 using a grid of hexagons instead of squares (i.e. a "honeycomb"). In this setting the threshold for toppling will be six instead of four.
